SI-923 Implantmed Classic Set – W&H

SI-923 Implantmed Classic Set – W&H – A high-quality, high-performance surgical motor is available for dental surgery, implantology and oral and maxillofacial surgery (OMS).

Key Features:

Ergonomic: due to the perfect balance between micromotor and handpiece the user can work for an extended period of time without their hand getting tired.
Simple: all programmes can be set using just one user level – either by using the foot control or the programme buttons on the device itself.
Powerful: with a motor torque of 5.5 Ncm and a motor speed range of 300 – 40,000 rpm, treatments can be performed with a high precision without the practitioner having to apply large amount of force.
Automatic thread cutter function that prevents excessive compression of the bone when inserting the implant. The result: Stress-free healing of the implant.

Technical Specifications:

Max. torque at the rotary instrument (in program 4)	70 Ncm
Mains Voltage	220-240 V
Frequency	50 – 60 Hz
Max. Mechanical Output Power	80 W
Max. Torque at the Motor	5.5 Ncm
Motor Speed Range in the Nominal Voltage Range	300 – 40,000 min ^-1
Length of Micromotor Cable	1.8 m
Coolant Flow Rate at 100 %	at least 90 ml/min
Height / Width / Depth	100 x 235 x 240 mm
